Description:

Custom Kawasaki ZX12R Engine built by George Dean w/Custom Ram-Air Box. 207 RWHP. Weight: 900 lbs. race-ready. Wet sump oiling with dual articulated pickups. No oil starvation as in the earlier dry sump system. Will accommodate driver up to 6'6" and 280 lbs. (me). Carbon Fiber 3 Piece Body w/Two-Color Professional Paint Job (Maroon/Silver gray). 3-Piece Carbon Fiber / Nomex Honeycomb Floor with Front & Rear Diffuser. 4130 Chrome-Moly Tubular Space Frame w/Dual SCCA Homologation (DSR & CSR). Fully Adjustable Inboard Suspension (camber, caster, toe & ride height, F & R). Adjustable Front and Rear blade-type Anti Roll Bar System. Inboard mounted Ohlins ST44 double-adjustable canister shocks (custom valved). Composite Front Dive Planes. Cockpit Edge Padding for Side Head Protection. Integral rollover protection. Kodiak forged aluminum wheels ( 7.5" x 13" front, 9.0"x13" rear) with Hoosier R35 tires (v.good condition). Aluminum "Crush Box" with Front Quick-Jack Points. Titan Motorsport Aluminum Rack & Pinion Steering . Taylor / Quiafe Torque Biasing Differential w/ Motion Protection. This Quaife unit is AMAZING! Adjustable Carbon Fiber Rear Wing with Infences (0 - 6 degrees) and interchangeable Gurney strips. SCCA Approved 9.5 Gallon Fuel Cell with Submerged Fuel Pump. SCCA approved lifting and towing points. Momo Steering Wheel (250mm) with Quick Release Hub. Custom Exhaust with JetHot 2000 Coating, 4 into 2 into 1. Wilwood Forged, 4 Piston Brake Calipers with Vented 10" Rotors. Wilwood 7112H Brake Pads. Wilwood Master Cylinders with Cockpit Adjustable Brake Bias (not a proportioning valve). Halon Fire System, 5lb, 2 outlet nozzles per SCCA GCR 17.22.1. 6 Speed Sequential Shifter (right side). AIM Mychron 3 Dash w/Data Logging. Odyssey Battery, Wiring Harness & SCCA Approved Master Switch. Billet Aluminum Suspension Uprights (interchangeable on all four wheels). "4340" Center-Lock Axles. Impact Racing 6-Point Harness & Custom Seat Kit. LED Rain and Brake Lights. Composite Inner Fenders (front & rear). OTHER Quick Jacks-front and rear. "Ready to Race" Package Includes 8 "quick-change" rear gear ratios (sprockets), for all track types. Extra set Kodiak wheels with brand new Goodyear slicks. Spare starter motor. Extra custom length chains included. Trackside IR beacon with internal and external batteries and tripod. Car will be delivered with fresh engine prepared by George Dean. Never raced. Used for 8 DE events (22 hours total) by our president. Car is in EXCELLENT condition Current FIA logbook. Full service history. This car is incredibly fast, incredibly stable and a joy to drive. It accelerates and corners like no other car I have ever driven. If a middle-aged amateur like me can do consistent 2:02's at the Glen imagine what you can do.


History

Merloy/Maloy CSR/DSR developed by Jim Maloy and the Andrettis as lightweight very powerful and competitive sports racer, then sold to Phoenix racecars. This car has not been raced, only used for DE events and always fully maintained. The 2006 model has upgraded suspension and aerodynamics. The twin to this car eas successfully driven by Jeremy Treadwell in the Nationals in 2005 and was in the lead when a wire loosened up causing a DNF. The CSR and DSR models are identical, and homologated for SCCA competition, with the CSR having the more powerful engine.

Competition History

Never raced
Performance Data

• CSR

• 900 lbs

• Lime Rock


Engine

• George Dean racing engines

• Kawasaki

• ZX12R

• 1200 cc

• 207 RWHP

• Ram air, EFI

• Kawasaki

• Kawasaki, alloy

• Custom

• Carillo

• Custom, 4 into 2 into one

• 22

• None

• Car supplied with fresh George Dean engine with 0 hours.


Fuel System

•

• Fuel Safe

• 8 months

• 9.5 gallons

• submerged

• 110 leaded


Oil/Water System

• Yes

• Left side pod

• Kawasaki

• Yes

• Right side pod


Electrical System

• coil on plug

• Kawasaki

• Odyssey

• Aim Mychron Gold

• George Dean remap


Transmission

• Kawasaki

• sequential

• 6

• Custom

• No

• 22 hours. no races

• Chain drive. Quick change rear sprockets


Rear End

• Maloy/Phoenix

• Sprocket

• No

• variable

• None-chain drive

• Quaife LSD

• Maloy/Phoenix half shafts

• 22 hours

• 8 final drive ratios possible with quick change sprocket


Body

• 3 piece carbon fiber/Kevlar

• Siver gray/Maroon

• PPG

• Excellent

• New paint


Chassis

• spaceframe

• Phoenix race cars

• 4130 chromemoly steel

• painted

• Excellent

• Custom aluminum uprights, unequal length wishbones, inboard coilover shocks, excellent

• Custom aluminum uprights, unequal length wishbones, inboard coilover shocks, excellent

• New. Ohlins St44, fully adjustable

• Wilwood forged

• Taylor Rack and Pinion, quick ratio

• Kodiak

• Goodyear/Hoosier (2 sets)


Interior

• Black/gray

• Carbon fiber

• Halon

• 6

• Aim Mychron Gold, programmable

• Momo, removable

• Excellent


Spares

• 1 set Kodiak rear wheels with new Goodyear slicks

• 1 starter motor

• 1 set Kodiak front wheels with new Goodyear slicks

• 1 set front brake pads

• 8 sets final drive sprockets

• 1 set rear brake pads

• 2 custom chains

• Full spares package (body, mechanicals) available at dealer cost
