Description:

RARE TVR Grantura 1800S---only 78 ever built! A race fan favorite shown in several vintage racing magazines. Restored 2000-2004 and built to Rocky Mountain Vintage Racing Specs(1972 SCCA PCS & GCR). Extensively upgraded for SVRA competition in 2008. Current SVRA annual tech. Suspension extensively tuned for neutral to slight under-steer, bump steered, very easy and predictable to drive. Logbboks clean(no deficiencies). Engine originally built by Dave Headley @ Fab-Tek; high output race engine good to 7500 RPM. Headley bottom end has been topped with a Burgess aluminum cross flow head and dual Webber carbs. Also a timing belt driven external oil pump has been added. Light weight and great brakes make this easy to drive hard into a corner! Excels on shorter, tight tracks, see SVRA times at Thunderbolt and Road Atlanta.


History

2006- Sandia win-see August 2006 Victory Lane, page 45. 2008 SVRA Group 3 Sprint Champion 2009 SVRA Group 3 2nd 4th Season Sprint Champioship overall 2009 SVRA VIR Group 3 7th overall 3rd in class out of 52 entrants 2009 SVRA Thunderbolt Group 3 fastest time of the race group 1,3,4 finishers podium. 2009 SVRA Road Atlanta 1st in classPerformance Data

• DP

• 1540 lbs


Engine

• Fab-Tek

• MG

• MGB 5-main

• 1850

• dyno sheets= 147HP

• 2-Weber 45 DCOE, flowed aluminum manifold

• Aluminum cross flow, ported and polished, re-shaped comb. chambers

• MGB

• MGB

• MGB ground and polished

• Carillo

• JE forged

• APT

• MG big valves

• roller rockers, adjustable pushrods

• 5 1/4 twin disc

• comp.

• alumnum w/steel insert

• custom headers, Duromax bullet muffler

• 7 hrs


Fuel System

•

• Fuel-Safe

• 7 years

• 10 gal

• Holley Red

• 110 Octane


Oil/Water System

• Griffin alum double pass

• front

• MGB

• oil-to-air

• front


Electrical System

• Petronix Ignitor and coil

• Odyssey sealed gel NEW

• n/a

• n/a


Transmission

• Quaife dog type

• close ratio gear set

• Quaife

• n/a

• 1.5 seasons


Rear End

• BMW

• Salisbury limited slip

• n/a

• 4.1:1

• BMW with custom machined alum mounts

• Triumph half shafts

• 1 year


Body

• fiberglass all panels

• Blue

• very good

• Lexan windshield, plexiglass rear with Dzus fasteners.


Chassis

• soac frame

• TVR

• steel tube

• painted

• excellent

• TVR wishbones, Triumph freeze-hardened trunnions and spindles, Hypercoil springs, custom anti-roll.

• IRS, TVR wishbones & hub carrier, hardened Triumph spindles, Avo springs, Addco anti-roll bar

• Avo gas adjustable, five years

• from Bremb/Triumph TR-4, Hawlk pads, rear TR-4 drums

• Triumph Spitfire rack

• real, Wolfrace, Indy Mag, 18 wheels 14" & 15"

• Toyo 14" Hossier Speedster


Interior

• painted grey

• fiberglass, aluminum

• extinguisher

• 5 pt. Crow, NEW December-2004

• tach, oil tem & pressure, water temp, volts, fueld pressure

• excellent


Spares

• numerous

• new complete spare race engine...$6500 if purchased with car or will sell separa
